Techanical Specifications:
|
|
|
| |
| Max. case size |
: |
480 mm x 752 mm |
| Min. case size |
: |
100 mm x 150 mm |
| Paper thickness |
: |
40 gsm -190 gsm |
| Board thickness |
: |
0.5 mm - 7 mm |
| Turning in Width |
: |
15 mm - 40 mm |
| Production |
: |
300 cases / h |
| Glue |
: |
hot / cold |
| Power |
: |
1.25 Hp (3phase) |
| Heater |
: |
2 Kw (single phase) |
| Dimensions |
: |
H 1150 x 2700 x W800 mm |
| Weight |
: |
750 kgs (approx) |
| Gluing System |
: |
Bottom |
| Man Power |
: |
Two |
| Pneumatic |
: |
6 - 10 bars |
| Materials |
: |
Paper, Laminated Paper,
Paper coated sheet, Rexin, Calico, etc |
| |
|
|
|
|
|
| |
|
|
|
| |
Modifications Reserved. Specifications not binding |
|
|
| |
| |
|
|
|
| |
|
| |
|
| |
